GENERAL FEATURES
• 136 - 174 MHz, 50 W
• 400 - 470, 450 - 520 MHz, 40 W
• 50 / 40 W @ 50 % Duty
• 25 / 25 W @ 100 % Duty
• Repeater Operation
• Duplex / Simplex Base Operation
• 30 CH Scanning Base
• Two-Digit LED Display
• 6 Lighted Programmable Function Keys
• Front Panel Speaker
• Rear External Speaker Output
(4 Watts Audio)
• Volume Control
• Program Interface
• Remote Termination Interface
• Programmable AUX I/O's
• RF Power Down Detect
• DTMF Front Panel PF Key Control
• DTMF AUX Output Control
• DTMF AUX Input Monitoring
• Windows® PC Programming
• Flash Firmware Upgrading
DIGITAL – CONVENTIONAL MODE
• NXDN® Digital Air Interface
• Conventional IP Network
• AMBE+2™ VOCODER
• 6.25 & 12.5 kHz Channels
• Mixed FM / Digital Operation
• NXDN® Scrambler Built-in
• 16 RAN Repeater Control Built-in
• 1,000 GIDs Per Site
• 1,000 UIDs Per Site
• Individual & Group Selective Call
• All Group Call
• NXR Over-the-Air Alias
FM MODES – GENERAL
• VHF: 25 & 12.5 kHz Channels
• UHF: 25 & 12.5 kHz Channels
• Built-in Scrambler
FM CONVENTIONAL MODE
• 16 QT / DQT Repeater Control Built-in
• Hang Timer / Time Out Timer / CW ID
• External FM Controller Interface
• EIA Voter Tone Generation
FM TRUNKED MODE
• External LTR® Controller Interface
• External MPT Controller Interface
