FEATURE HIGHLIGHTS
• Multi-Digital operation in NXDN, DMR, and P25
(Phase 1 & 2) protocols
• Any combination of two digital protocols can
be selected from NXDN, DMR, and P25
• Mixed Digital & FM Analog Operation allows
intelligent migration in mixed sites and easy
migration with digital radios in other sites
• Large, Color 2.55" (154 x 422 pixels) TFT
Display for at-a-glance operational status checking
• Easy to follow GUI and Multi-line Text to convey
more information
• Dual Remote Control Head and Multi-Band (Multi
RF Deck) Control Option providing scalable
configurations for various operations and applications
• Built-In GPS Receiver for effective fleet management
• Bluetooth® Module built-in for hands-free operation
• Renowned KENWOOD Audio Quality can be
achieved with Active Noise Reduction (ANR)
that utilizes built-in DSP with two microphones for
suppression of ambient noise
• Built-in 56-bit DES Encryption
• Optional 256-bit AES Encryption
• Over-the-Air Programming (OTAP)
• microSD/SDHC (up to 2GB/32GB) Card Slot
• IP54/55 and MIL-STD-810 C/D/E/F/G
GENERAL FEATURES
• 50 W to 5 W (136-174 MHz) Models
• 45 W to 5 W (380-470, 450-520 MHz) Models
• 30 W to 2 W (700 MHz) Model
35 W to 2 W (800 MHz) Model
• Maximum of 4,000 CH/Radio capacity,
512 CH/Zone, 128 Zones
• DB-25 Accessory Connector
• AMBE+2™ Enhanced Vocoder
• 4 W Speaker Audio
DIGITAL – NXDN MODE
• Gen2 & NXDN Type-C Trunked Operation
• NXDN Conventional Operation
• 6.25 & 12.5 kHz Channel Spacing
• Over-the-Air Alias
• Paging Call
• Emergency Call
• All Group Call
• Status Messaging
• Remote Stun/Kill
• Remote Check
• Short & Long Data Messages
• NXDN Digital Scrambler Included
DIGITAL – DMR MODE
• S-Trunking
• DMR Tier III Trunking
• DMR Tier II Conventional
• DMR Auto Slot Select
• Enhanced Encryption (40-bit)
• Site Roaming
• Two-slot TDMA in 12.5kHz channels
• Call Interruption
• Dual-slot Direct Mode
• Energy Efficient
DIGITAL – P25 MODE
• P25 Phase 1 Conventional/Trunked Operation
• P25 Phase 2 Trunked Operation
• Talk Group ID Lists/• Individual ID Lists
• Caller ID Display
• Remote Monitor/Remote Check
• Radio Inhibit
• Encryption Key Zeroize & Retention
• P25 Enhanced Encryption (ARC4)
• Over-the-Air Re-keying
FM MODES – GENERAL
• Conventional & LTR Zones
• FleetSync®/II: PTT ID ANI / Caller ID Display,
Selective / Group Call, Emergency Status / Text
Messages
• MDC-1200: PTT ID ANI / Caller ID Display,
Emergency, Radio Check / Inhibit
• QT / DQT & Two-Tone
• Built-in Voice Inversion Scrambler
MULTIPLE CONFIGURATIONS
The NX-5000 mobile series allows users to create a
variety of configurations to suit different requirements
by combining different options. Some of the standard
configurations are:
• Single Remote Control Head x Single RF Deck
• Dual Remote Control Heads x Single RF Deck
• Dual Remote Control Heads x Multi RF Decks
• Other combinations are available. Consult
your local KENWOOD dealer for more.
